특징
- 표준 19 인치 랙마운트 크기
- LCD 패널을 통한 쉬운 IP 주소 설정 (광범위 온도 모델 제외)
- 텔넷, 웹 브라우저 또는 Windows 유틸리티를 사용하여 설정
- 소켓 모드 : TCP 서버, TCP 클라이언트, UDP
- 네트워크 관리를 위한 SNMP MIB-II
- 고전압 범위 : 100 ~ 240 VAC 또는 88 ~ 300 VDC
- 저전압 범위 : ± 48VDC (20 ~ 72VDC, -20 ~ -72VDC)
인증
Ethernet
Interface
|
10/100BaseT(X) Ports
(RJ45 connector) |
1 |
|
Magnetic Isolation Protection |
1.5 kV (built-in) |
|
Optical Fiber |
separately marked |
Ethernet
Software Features
|
Configuration Options |
Telnet Console, Windows Utility, Web Console
(HTTP/HTTPS) |
|
Management |
ARP, BOOTP, DHCP Client, DNS, HTTP, HTTPS, ICMP,
IPv4, LLDP, RFC2217, Rtelnet, PPP, SLIP, SMTP, SNMPv1/v2c, TCP/IP, Telnet,
UDP |
|
Filter |
IGMP v1/v2 |
|
Windows Real COM Drivers |
Windows
95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8/8.1/10 (x86/x64), Windows
2008 R2/2012/2012 R2 (x64), Windows Embedded CE 5.0/6.0, Windows XP Embedded |
|
Fixed TTY Drivers |
SCO UNIX, SCO OpenServer, UnixWare 7, QNX 4.25, QNX
6, Solaris 10, FreeBSD, AIX 5.x, HP-UX 11i, Mac OS X |
|
Linux Real TTY Drivers |
Kernel version: 2.4.x, 2.6.x, 3.x, 4.x |
|
Android API |
Android 3.1.x and later |
|
Time Management |
SNTP |
Serial
Interface
|
Connector |
8-pin RJ45 |
|
No. of Ports |
8 or 16 ports |
|
Serial Standards |
NPort 5610 Series: RS-232 NPort 5630 Series: RS-422, RS-485 NPort 5650 Series: RS-232, RS-422, RS-485 |
|
Operation Modes |
Disabled, Ethernet Modem, Pair Connection, Real COM,
Reverse Telnet, RFC2217, TCP Client, TCP Server, UDP |
|
Baudrate |
Supports standard baudrates (unit=bps): 50, 75, 110,
134, 150, 300, 600, 1200, 1800, 2400, 4800, 7200, 9600, 19200, 38400, 57600,
115200, 230.4k, 460.8k, 921.6k |
|
Data Bits |
5, 6, 7, 8 |
|
Stop Bits |
1, 1.5, 2 |
|
Flow Control |
None, RTS/CTS (RS-232 only), DTR/DSR (RS-232 only),
XON/XOFF |
|
Parity |
None, Even, Odd, Space, Mark |
|
Pull High/Low Resistor for RS-485 |
1 kilo-ohm, 150 kilo-ohms |
|
RS-485 Data Direction Control |
ADDC® (automatic data direction control) |
|
Terminator for RS-485 |
120 ohms |
Serial
Signals
|
RS-232 |
TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND |
|
RS-422 |
Tx+, Tx-, Rx+, Rx-, GND |
|
RS-485-4w |
Tx+, Tx-, Rx+, Rx-, GND |
|
RS-485-2w |
Data+, Data-, GND |
Power
Parameters
|
Input Current |
NPort 5610-8-48V/16-48V: 135 mA @ 48 VDC NPort 5650-8-HV-T/16-HV-T: 152 mA @ 88 VDC NPort 5610-8/16: 141 mA @ 100 VAC NPort 5630-8/16: 152 mA @ 100 VAC NPort 5650-8/8-T/16/16-T: 158 mA @ 100 VAC NPort 5650-8-M-SC/16-M-SC: 174 mA @ 100 VAC NPort 5650-8-S-SC/16-S-SC: 164 mA @ 100 VAC |
|
Input Voltage |
HV Models: 88 to 300 VDC AC Models: 100 to 240 VAC, 47 to 63 Hz DC Models: ±48 VDC, 20 to 72 VDC, -20 to -72 VDC |
Reliability
|
Automatic Reboot Trigger |
Built-in WDT |
Environmental
Limits
|
Operating Temperature |
Standard Models: 0 to 55°C Wide Temp. Models: -40 to 75°C High-Voltage Wide Temp. Models: -40 to 85°C |
|
Storage Temperature (package included) |
Standard Models: -20 to 70°C Wide Temp. Models: -40 to 75°C High-Voltage Wide Temp. Models: -40 to 85°C |
|
Ambient Relative Humidity |
5 to 95% (non-condensing) |
MTBF
|
Time |
NPort 5610-8: 877,888 hrs NPort 5610-8-48V: 870,961 hrs NPort 5610-16: 666,105 hrs NPort 5610-16-48V: 662,111 hrs NPort 5630-8: 765,449 hrs NPort 5630-16: 473,748 hrs NPort 5650-8: 692,010 hrs NPort 5650-8-T: 692,010 hrs NPort 5650-8-HV-T: 627,078 hrs NPort 5650-8-M-SC: 678,053 hrs NPort 5650-8-S-SC: 678,053 hrs NPort 5650-16: 473,748 hrs NPort 5650-16-T: 473,748 hrs NPort 5650-16-HV-T: 442,626 hrs NPort 5650-16-M-SC: 467,180 hrs NPort 5650-16-S-SC: 467,180 hrs |
|
Standards |
AC models: MIL-HDBK-217F HV models: Telcordia (Bellcore) Standard TR/SR |
Warranty
|
Warranty Period |
5 years |
|
Details |
Contact us |
Physical
Characteristics
|
Housing |
Metal |
|
Installation |
19-inch rack mounting |
|
Dimensions (with ears) |
480 x 45 x 198 mm |
|
Dimensions (without ears) |
440 x 45 x 198 mm |
|
Weight |
NPort 5610-8: 2,290 g NPort 5610-8-48V: 3,160 g NPort 5610-16/5630-16: 2,490 g NPort 5610-16-48V: 3,260 g NPort 5650-8/5650-8-T: 2,310 g NPort 5650-8-M-SC: 2,380 g NPort 5650-8-S-SC/5650-16-M-SC: 2,440 g NPort 5650-8-HV-T: 3,720 g NPort 5650-16/5650-16-T: 2,510 g NPort 5650-16-S-SC: 2,500 g NPort 5650-16-HV-T: 3,820 g |
|
Interactive Interface |
LCD panel display (standard temp. models only) Push buttons for configuration (standard temp.
models only) |
Standards
and Certifications
|
EMC |
EN 55032/24 |
|
EMI |
CISPR 32, FCC Part 15B Class A |
|
EMS |
NPort 5650-8/16 Series: IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m IEC 61000-4-4 EFT: Power: 4 kV; Signal: 2 kV IEC 61000-4-5 Surge: Power: 2.5 kV; Signal: 1 kV IEC 61000-4-6 CS: 150 kHz to 80 MHz: 3 V/m; Signal:
3 V/m IEC 61000-4-8 IEC 61000-4-11 DIPs
NPort 5650-8/16-HV Series: IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m IEC 61000-4-4 EFT: Power: 4 kV; Signal: 2 kV IEC 61000-4-5 Surge: Power: 2 kV IEC 61000-4-6 CS: 150 kHz to 80 MHz: 3 V/m; Signal:
3 V/m IEC 61000-4-8 |
|
Medical |
EN 60601-1-2 Class B, EN 55011 |
|
Safety |
UL 60950-1 |
| NAME | Download | VERSION |
| NPort 5000_RealCOM_모드 | https://www.yoisys.com/inc/download/form.php?id=108 | V1.0 |
| NPort_TCP_Client_모드 | https://www.yoisys.com/inc/download/form.php?id=110 | V0.9 |
| NPort_TCP_Server_모드 | https://www.yoisys.com/inc/download/form.php?id=111 | V0.9 |
Optical Fiber
|
|
100BaseFX |
|||
|
Multi-Mode |
Single-Mode |
|||
|
Fiber Cable Type |
OM1 |
50/125 µm |
G.652 |
|
|
800 MHz x km |
||||
|
Typical Distance |
4 km |
5 km |
40 km |
|
|
Wavelength |
Typical (nm) |
1300 |
1310 |
|
|
TX Range (nm) |
1260 to 1360 |
1280 to 1340 |
||
|
RX Range (nm) |
1100 to 1600 |
1100 to 1600 |
||
|
Optical Power |
TX Range (dBm) |
-10 to -20 |
0 to -5 |
|
|
RX Range (dBm) |
-3 to -32 |
-3 to -34 |
||
|
Link Budget (dB) |
12 |
29 |
||
|
Dispersion Penalty (dB) |
3 |
1 |
||
|
Note: When
connecting a single-mode fiber transceiver, we recommend using an attenuator
to prevent damage caused by excessive optical power. |
||||
8 포트 및 16 포트 RS-232/422/485 랙마운트 시리얼 디바이스 서버
